Cov yam ntxwv tseem ceeb ntawm 10Kwh Battery Storage System rau Tsev
♦ Nrog Standard Chassis Design
Siv kev tsim qauv tsim, nruj thiab tsim qauv, nrog ntau yam muaj zog, kev teeb tsa yooj yim, kev ua haujlwm yooj yim, thiab kev saib xyuas zoo.
♦ UltraLub neej ua haujlwm ntev
Lub siab -kawg hom lithium hlau phosphate cell, xws li EVE, CATL, nrog qis sab hauv tsis kam thiab tus nqi siab. Kev nyab xeeb siab dua, ntau dua 4000 lub voj voog lub neej ntawm chav tsev kub, kev pab lub neej ntev dua.
♦ Safer thiab Smarter
Lub kaw lus ntse tuaj yeem txo qhov poob, txhim kho lub zog hloov pauv kev ua haujlwm, muaj kev ruaj ntseg dua, thiab khiav zoo thiab ntse..
♦ Tsim- hauv Pro BMS thiab Kev Sib Txuas Lus Ua Haujlwm
Kev siv peb -theem BMS kev tswj hwm kev tswj hwm kom tsis txhob muaj qhov tsis txaus ntawm cov xov tooj ntawm tes thiab kev tshaj tawm thiab tshaj tawm los ntawm nws mus rau qhov loj tshaj plaws, thiab tseem tuaj yeem paub txog tag nrho cov txheej txheem saib xyuas thiab kev tswj hwm ntawm lub system.
♦ Txhawb Parallel thiab Ntau Inverters
Lub roj teeb no tuaj yeem txhawb nqa txog 15 daim ntawv thov sib npaug, uas tuaj yeem ua tau raws li kev siv lub peev xwm loj dua, thaum txhawb nqa CAN2.0, RS485 thiab RS232 kev sib txuas lus raws tu qauv. Kev sib piv ntau lub inverters kuj yog ib qho zoo tshaj plaws ntawm lub roj teeb no.
♦ Ib puag ncigProtection thiabSkev nyab xeeb
LiFePO4 tsis muaj teeb meem thiab tsis muaj kuab paug, tsis muaj pa phem, thiab tsis tawg. Huanduy LiFePO4 yog qhov kev xaiv zoo tshaj plaws rau kev txhim khu kev qha, nyab xeeb, thiab ib puag ncig kev daws teeb meem.
|
Qhov System Parameter |
|||
|
Qhov system muaj peev xwm |
10.4 kwm |
15,6 qw |
20.8 qw |
|
Number of parallel roj teeb |
2 |
3 |
4 |
|
Roj teeb pob muaj peev xwm |
200 Aw |
300 Aw |
400 Aw |
|
Qhov hnyav |
180kg ib |
230kg ua |
280kg ua |
|
Ntsuas |
600 * 600 * 860 hli |
600 * 600 * 1130 hli |
600 * 600 * 1400 hli |
|
Max input zog |
5 kws |
||
|
Maximum tso zis zog |
5 kws |
||
|
Hom roj teeb |
Lithium hlau phosphate |
||
|
Kev tiv thaiv qib |
IP40 |
||
|
Lub neej |
Ntau tshaj lossis sib npaug rau 4000cycle |
||
|
Roj teeb Parameters |
|||
|
Rated voltage ntawm roj teeb |
51.2V |
Peak tawm tam sim no |
110A |
|
Ua haujlwm voltage ntawm roj teeb |
40~58.4V |
Txias hom |
Ntuj cua txias |
|
Kev sib txuas lus interface |
CAN / RS232 / RS485 |
Qib waterproof |
IP40 |
|
Nruam them tam sim no |
100A |
Kev them nyiaj kub |
0 ~ 60 degree |
|
Nruam tawm tam sim no |
100A |
Tshem tawm kub |
-20 ~ 60 degree |
|
Peak charging tam sim no |
110A |
Humidity ntawm qhov chaw ua haujlwm |
10% -90% RH |
|
Hloov cov Inverter Parameters |
MPPT Parameters | ||
|
Kev them nyiaj siab tshaj plaws |
5 kws |
Qhov siab tshaj plaws PV qhib Circuit Court voltage |
145 Vdc ib |
|
Maximum tso zis zog |
5 kws |
PV kev ua haujlwm voltage ntau |
60 ~ 145VDC |
|
DC input voltage ntau |
40~60V |
MPPT voltage ntau |
60 ~ 145VDC |
|
DC tso zis voltage ntau |
40~58V |
Maximum tso zis zog |
4200W |
|
tus lej ntawm theem |
monophase |
Hnub ci them tam sim no |
0~80A |
|
Rated AC input |
220V |
||
|
Rated AC tso zis voltage |
220V |
||
|
rated zaus |
50/60Hz |
||
Safer Thiab Ntse
Vim li cas CoPow Roj Teeb muaj kev nyab xeeb dua
Yog vim li cas CoPow Roj teeb yog Smarter
CoPow roj teeb, nyab xeeb thiab ntse dua, ib txwm txias.
Koj Superior Supplierrau10Kwh Battery Storage System rau Tsev
★ Kev nplua nuj nyob hauv Energy Storage Systems
Huanduy tsom ntsoov rau kev tsim cov khoom siv hluav taws xob muaj zog ntau dua. Pab neeg ua haujlwm sib txuas cov huab cua hloov pauv, kev tsim hluav taws xob hnub ci, thiab cov ntaub ntawv siv hluav taws xob los kho koj lub roj teeb. Ntau cov qauv tsim ntse los txuas ntxiv txhim kho lub zog ua haujlwm thiab roj teeb ua haujlwm.
★ Pab pawg muaj zog
Huanduy's R & D pab neeg yog los ntawm BYD, CATL, thiab EVE. Pib nrog kev sib tham, engineers npaj, tsim, thiab nruab lub zog cia rau koj.
★ Tswj nruj kom zoo
Lub Hoobkas nruj me ntsis tswj cov txheej txheem ntau lawm thiab tshuaj xyuas kom ntseeg tau tias cov roj teeb ruaj khov. Peb muab cov roj teeb uas muaj kev nyab xeeb tshaj plaws rau koj. Peb cov khoom tau dhau qhov kev tshuaj xyuas hauv qhov ntsuas qhov ua tau zoo thiab kev ua haujlwm zoo. Huanduy 10kWh hnub ci phab ntsa-mounted lithium roj teeb txais 18650 lithium hlau phosphate roj teeb. Tag nrho cov khoom siv sab hauv yog ntsia hlau- fastened, ua rau koj lub zog cia roj teeb muaj zog thiab ruaj khov dua.
★ Daim ntawv pov thawj kws tshaj lij
Cov khoom tau dhau CE, IEC, UN38.8, UL, thiab lwm yam ntawv pov thawj.
★ Scientific Customization
Raws li ib qho ntawm cov tuam txhab roj teeb lithium-ion roj teeb, Huanduy tuaj yeem kho cov roj teeb sib txawv (voltage: 12 ~ 48V; muaj peev xwm: 50Ah ~ 600ah). Ua kom cov inverters, roj teeb, thiab lub hnub ci vaj huam sib luag kom ua kom lub zog loj dua. Muab cov tswv tsev thiab cov lag luam nrog hluav taws xob txuas ntxiv.
TOP CoPow R&D Team
Nrog 20 xyoo dhau los ntawm qhov nruab nrab
Nrog tshwj xeeb-tseem ceeb cov kws tshaj lij ua tus pob txha,
CoPow R & D pab neeg tsis tu ncua rau kev tsim kho thev naus laus zis.
Cov txheej txheem tseem ceeb ntawm LiFePO4 roj teeb
Nrog rau kev tswj hwm kev nyab xeeb zoo tshaj plaws, kom ua tiav kev saib xyuas cov khoom zoo, txhim kho peb cov kev ua haujlwm zoo, txhim khu kev qha kev tswj xyuas zoo tuaj yeem tiv thaiv koj cov kev txaus siab. Cov ntaub ntawv pov thawj 10kwh roj teeb cia rau hauv tsev ua rau koj ntseeg tau ntau dua.
Widely Compatible Inverters
Daim ntawv thov
Huanduy 10KWH roj teeb lub zog tuaj yeem txo koj qhov kev cia siab ntawm daim phiaj hluav taws xob. Peb lithium-ion hnub ci cell yog zoo meej los txhim kho kev ywj pheej ntawm hluav taws xob hauv tsev. Lub zog ntau dhau yuav muab khaws cia thiab ua kom muaj thaum xav tau!
Txo koj cov nqi hluav taws xob los ntawm kev siv lub zog hluav taws xob 10 kWh kom tsis txhob yuav hluav taws xob thaum cov nqi hluav taws xob nce siab.
Huanduy 10KWH yog lub tshuab hluav taws xob ceev ceev ceev lub zog cia. Txo cov teeb meem thiab kev poob uas tshwm sim los ntawm hluav taws xob tam sim ntawd.
Lithium hlau phosphate roj teeb yog lub zog ntsuab txuas ntxiv. Huanduy 10KWH muab lub zog huv thiab ruaj khov rau koj lub tsev cia khoom.
Yooj yim configuration. Nyob ntawm qhov loj ntawm qhov module, lub peev xwm cia nce mus rau 20 kWh lossis ntau dua!
Huanduy 10 kW txais cov cuab yeej ntse thiab kev nyab xeeb kom ua kom lub roj teeb lub neej ntev thiab kev nyab xeeb. Lub voj voog sib sib zog nqus thiab kev saib xyuas dawb, ntxiv txo koj cov nqi hluav taws xob.
Lub teeb yuag tsim ua kom yooj yim installation. Cov khoom siv hauv tsev tsis muaj dej tsis zoo thiab tsis muaj plua plav, thiab lub pob roj teeb ua haujlwm ntawm -20℃mus rau 50℃(-4℃F txog 122℃F), ua rau nws lub zog zoo hauv tsev cia.
Kev tshuaj xyuas neeg siv khoom
CoPow roj teeb, nyab xeeb thiab ntse dua, ib txwm txias.
Ib txwm saib xyuas los ntawm cov neeg siv khoom thoob plaws ntiaj teb.
FAQ
(1). Yuav ua li casLongCib 10kwBroj teebPower ibHsiv?
Feem ntau, thaum muaj hluav taws xob hluav taws xob, tsev neeg nruab nrab siv 750W txog 1,000W ib teev, thiab lub roj teeb 10 kWh yuav kav 10 mus rau 12 teev.
(2). UaSolarPanelsWork thaum aPtus tswvOsiv?
Tsis yog, rau cov laj thawj kev thiab kev nyab xeeb, lub hnub ci yuav tsis muab lub zog thaum lub zog hluav taws xob. Hnub ci vaj huam sib luag yog tsim los nqus lub hnub ci thiab hloov mus rau hauv hluav taws xob.
(3). Ua tauHkhoom sivElectricity uaRib on aSolarSsystem ib leeg?
Niaj hnub nimno hnub ci tshuab pab peb nrog hluav taws xob cia, thiab koj tuaj yeem ua tau
khiav koj lub tsev hluav taws xob tag nrho ntawm lub hnub ci zog. Lub hnub ci fais fab yog qhov pheej yig tshaj plaws los siv hluav taws xob tag nrho lub tsev.
(4). Ua tauSolarPanelsWork uaRib aiDaws?
Lub hnub ci vaj huam sib luag tseem nqus cov teeb pom kev hauv nag tab sis tsim hluav taws xob tsawg. Los nag kuj zoo rau cov hnub ci vaj huam sib luag, thiab koj tuaj yeem tau txais kev pab tu vaj huam sib luag dawb.
(5). Yog 10 kWEnug toRib aHsiv?
Nws nyob ntawm seb koj nyob qhov twg. Lub 10kW hnub ci zog tuaj yeem siv tau rau tsev neeg nruab nrab ntawm plaub. Lub tshuab hluav taws xob 10kW hnub ci tsim tau qhov nruab nrab ntawm 40kW ib hnub thiab tuaj yeem khiav cov khoom siv hauv tsev rau ntau tshaj 5 chav pw, suav nrog txhua lub teeb, TVs, laptops, tub yees, tshuab ntxhua khaub ncaws, thiab cua txias hauv nruab nrab.
(6). Dab tsiDcov eviceCib 10kWBroj teebPtus tswv?
Piv txwv li, 33 teev rau 300W TV; 50 teev rau 200W tub yees; 50 teev rau tsib 20W qhov muag teev; 25W xov tooj charger rau 400 teev; los yog 6W WiFi router rau 1,600 teev. Lub kaw lus muaj peev xwm khiav tau 8 LED teeb, 8 kiv cua, 2 tons ntawm AC (2 lub tub yees, 1 lub tshuab ntxhua khaub ncaws, 1 lub tub yees)
